Toyota Hilux 4dr Ute Dual Cab 04/05-09/15 Rhino-Rack Heavy Duty Track Mount Roof Racks (pr) (JA6233)

In Stock

RRP $891.00
$757.35 AUD*Price Match Guarantee
Save $133.65 (15% Off)

Bar Type: Track Mount
Brand: Rhino-Rack

This Vortex Quick Mount™ RLT600 roof rack system is fixed to your roof using a specialised track. However, the legs and cross bars can be easily removed when they are not required using a simple trigger locking system.


Utilising our highly regarded Vortex bars, this system offers you compatibility with a wide selection of Rhino-Rack accessories. So whether you’re a traveller, kayaker, surfer, cyclist or tradesperson – the Vortex RLT600 roof rack system has you covered.

Key Features:
Installation or removal in three easy steps, no tools required
Ideal for low clearance
A lockable cover plate that protects the locking mechanism, Masterkey™ compatible
Fits the Rhino-Rack Vortex Bar, with a fitting kit available for the Heavy Duty Bar and Pioneer models
The base and leg allows for 33 degrees of swivel to suit tracks mounted on a countoured or curved surface
Single person operation allows quick and easy attachment
Simple trigger locking system
Maximum load capacity across 2 bars is 100kg (always refer to the vehicle maximum load rating and use the lower of the two)
Tested to AS1235:2000 (Australian), ISO11154:2006 (City Crash/International) standards
Lifetime Warranty

1x RTS03 Tracks to suit Toyota Hilux.

2x RB1375 Heavy Duty Bars (1375mm Black)

1x RLT600 Quick Mount Leg Set

1x QMW05 Quick Mount Base Wedge (5mm)

2x QMHD05 Quick Mount Heavy Duty Spacer 5mm

Additional information



  • Mount Style: Track Mount
  • Bar Style: Overhang Bar
  • Fixture: Fixed
  • Warranty: Lifetime
  • Colour: Silver
  • Bar Length: 1375mm
  • Leg Profile: RLT600
  • Track Type: RTS
  • Bar Type: Vortex
  • # Of Bars: 2
